| Manufacturer | APEM Inc. | |
|---|---|---|
| Series | G | |
Packaging  | Bulk | |
| Part Status | Active | |
| Circuit | SPDT | |
| Contact Timing | Not Specified | |
| Switch Function | On-On | |
| Current Rating | 3A (DC) | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Standard | |
| Actuator Length | 5.10mm | |
| Contact Material | Silver (Ag) | |
| Contact Finish | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Features | Epoxy Sealed Terminals | |
| Operating Temperature | -30°C ~ 85°C | |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled | |
| Switch Travel | 2.20mm | |
| Mechanical Life | - | |
| Electrical Life | 40,000 Cycles | |
| Operating Force | - |
